8000 Series Overview

Medallion’s 8000 Series is one of our many solutions for Industrial, Commercial and Institutional applications. Our many designs provide the distinctive look of ornamental fencing with the required security that is demanded. Unsurpassed corrosion protection by utilizing Flo Coat® the superior triple coated steel or where required High Tensile Marine Grade Aluminum where required.

8000 Series Features & Specifications

undefined

ARMOUR-SHIELD™ Protection
Allied Flo Coat® Triple Coated Steel
Stainless Steel Welds
Super Durable Polyester Powder Coated
Rails: 38mm x 38mm (1-1/2" x 1-1/2")
Pickets: 25mm x 25mm (1" x 1")
Posts Minimum: 64mm x 64mm (2-1/2" x 2-1/2")

undefined

Alu-Tuff™ Protection
Marine Grade Aluminum
Aluminum Mig Welds
Super Durable Polyester Powder Coated
Rails: 38mm x 38mm (1-1/2" x 1-1/2")
Pickets: 25mm x 25mm (1" x 1")
Posts Minimum: 64mm x 64mm (2-1/2" x 2-1/2")

Medallion 8000 Series Armour-Shield™

Solid Tube Rails
Interior Weld Seam Zinc Coated
Chromate Conversion Coating
Organic Clear Coat Sealer / Primer
JS1000™ Plating on Bracket Fasteners
Super Durable Polyester Powder Coat
3000 Hours Salt Spray ASTM-B117

Other Brands

Open Channel Rails
Interior Weld Seam Left Unprotected
No inline Chromate Conversion Coating
No Organic Clear Coat Sealer / Primer
Standard Grade Plating on Fasteners
Regular Grade Polyester Powder Coat
800 – 1000 Hours Typical

Architects - Specifiers - Developers Open Access to our resource library of drawings & specifications
